产品参数/Product parameters | |
产品型号/Model | TZ-QRGD-C15 |
灯具类型/Luminaire type | 泛光/格栅/方形格栅/导轨灯 |
电源电压/Supply Voltage | DC 48V |
色温/colour temperature | ■2700K ■3000K ■3500K ■4000K■定制色温/Custom color temperature |
显色指数/Color Rendering Index | ■≥90 |
光束角/Beam Angle | ■15°■24°■36°■120° |
材质/texture of wood | 压铸铝/Die Cast Aluminum |
安装方式/Installation mode | 嵌入式安装/Embedded installation |
调光协议/Dimming protocol | 0-10V/DALl/蓝牙/ZIGBEE |
防护等级/Protection level | IP20 |
功率/power | ■4W-30W |
光源/Light cource | SMD、COB |
输入电压/Input Voltage | AC 220-240V |
色容差/Color tolerance | <3 |
驱动/drive | 内置/外置built-in/external |
灯具颜色/Colour of Luminaires | 白色/黑色/其他/White/black/others |
频闪控制/Strobe control | 高频无频闪/No strobe at high frequency |
额定寿命/Rated life | 40000H |
操作环境/Operating Environment | -15°~ +45° |
应用场合/Applications | 酒店 别墅 办公等综合体/Hotel, Villa, office complex |
